Riser Clamp Kits

Measurements Available: Metric

Riser Clamp Kits

Riser Clamp Kits

The MITEE-BITE Riser Clamp Kit is a low profile adjustable system, somewhat like a vice, designed to be used directly in the T-slots of most knee mills or on our Aluminum T-Slot sub plates. The locating rail is indicated to the table and the clamps are moved along the T-Slots of the machine table to accept different size work pieces on both sides of the rail.

  • Ideal for mill-thru and drill-thru operations
  • Allows quick set-up directly on machine table and sub plates
  • Available for different size T-slots, including metric.
Riser Clamp Kits
Part No. Item A B C D +.0000
-.0005
E F G H
23100 CAD Locating Rail 127.0 31.50 18.30 11.684 18.80 63.5 24.90 50.3
53140 CAD Clamping Base 63.5 19.05 15.75 11.684 7.88 21.08 NA NA
* D – minimum clamp height.
Riser Clamp Kits
Part No. Item A B C D +.0000
-.0005
E F G H
51440 CAD Locating Rail 198.0 43.94 31.24 12.192 21.84 99.0 50.0 80.26
51014 CAD Clamping Base 53.5 28.45 15.75 12.192 6.35 19.81 NA NA
* D – minimum clamp height.

Riser Clamp Kits


Part Number T-Slot Size
Mini Riser Kit Kit Contents
51250 12 4 clamp base assemblies
51450 14 2 hex keys
51650 16
51850 18
Part Number T-Slot Size
Universal Kit Kit Contents
51088 10 1 locating rail with stop
51288 12 4 clamp base assemblies
51488 14 3 hex keys
51688 16
51888 18
